RX-57XT8OFF6
Introducing the AMD Radeon™ RX 6000 Series graphics cards, featuring the breakthrough AMD RDNA™ 2 architecture, engineered to deliver powerhouse performance for all gamers. The AMD Radeon™ RX 6800 Series graphics cards power a new generation of competitive and 4K gaming with vivid visuals, and elevated experiences in every game and every frame.
Model Number RX-57XT8OFF6
Product Name AMD Radeon™ RX 5700 XT
Product Description RADEON RX 5700 XT 8G D6 RAW II 3xDP HDMI
Launch Date Aug,2019
UPC Number 778656077584
Bus Type PCI-E 4.0
Base Clock 1605MHz
Game Clock 1755MHz*
Boost Clock Up to 1905MHz**
Stream Processors 2560
Memory Bus 256 bit
Memory Clock 14 Gbps
Memory Size 8 GB
Memory Type GDDR6
Card Profile 2.9 slot
Thermal Solution DD Fansink
*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
**"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
Dual link Support Y
Max Supported Resolution (DIGITAL) up to 8K resolution at 60 Hz or 5K at 120 Hz
Output - Display Port 3
Output - HDMI 1
External Power - 8-pins 1
External Power - 6-pins 1
Minimum Power Supply Requirement 600 watt
XFX Recommended Power Supply XFX 600W PSU
RoHS
8-pin to 6-pin power cable 1
6-pin to 4-pin power cable 1
Driver Disk Installation Guide 1
Installation DVD 1
Card Dimension (cm) 27.8 x 14 x 5.8
Card Dimension (inch) 10.94 x 5.51 x 2.28
Master Carton Dimensions (cm) 49.7 x 33.5 x 36.8
Master Carton Dimensions (inch) 19.57 x 13.19 x 14.49
Master Carton Weight (Kg) 13.5 est.
Master Carton Weight (lb) 29.7 est.
Package Dimensions (cm) 34 x 24 x 8
Package Dimensions (inch) 13.39 x 9.45 x 3.15
Package Weight (Kg) 1.54 est.
Package Weight (lb) 3.39 est.
Units/Carton 8
RDNA Architecture
2nd Gen 7nm GPU
GDDR6 Memory
Power Efficiency
PCI® Express4.0 Support
Video Streaming up to 8K
DisplayPort 1.4w/DSC
Radeon™ Image Sharpening
Async Compute
Radeon™ Rays Audio + True Audio Next
Radeon™ Freesync™ 2 HDR*
Radeon™ VR Ready Premuim
Radeon™ Software
Driver Optimizations
Radeon™ Boost
RDNA architecture
Advanced 7nm GPU
PCI Express 4.0 Support
Radeon Image Sharpening
FidelityFX
Radeon Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
AMD Virtual Super Resolution (VSR)
AMD Relive
AMD FreeSync 2 HDR
AMD Frame Rate Target Control (FRTC)
AMD Eyefinity multi-display technology
AMD Radeon Adrenalin Software 2019
AMD WattMan
HDMI 2.0b
Displayport 1.4 w/ DSC
Dolby TrueHD and DTS-HD Master Audio Support
Up to 6 displays supported, (may require the use of MST Hubs)
OpenGL 4.5 Support
OpenCL Support
Power when you need it and quiet when you don't. XFX fans are equipped to run at the highest possible performance, while our Zero DB Fan System will also keep your fans running at efficient RPM in order to minimize annoying fan noise by lowering RPM all the way down to Zero RPM. When the heat is on during intense gaming, our fans will speed up as needed.
Giving you the performance you have come to expect from XFX. Even though we trust that our high quality products will continue working at peak performance well beyond your use of it, we want to put our word behind that promise. That is why we offer our 3 Year Warranty with this series of graphics cards. This means that your product is protected by a 3 year limited hardware warranty on manufacturing defects of anything on the card.
Download the latest version of Radeon™ Software and take advantage of performance enhancing features like Radeon™ Boost and Radeon™ Anti-Lag, as well as optimized game day-0 drivers.
